.This Huckbolt riveting tool is ideal for many truck and trailer repair applications. It is also designed to install the C98LT stainless steel polished Huck bolts used on the Peterbilt Truck Cab grills. These tools are often referred to as Huck tools. Also included are wrenches for service and oil applicator.
A structural, two-piece fastener, which consists of a pin (C6L lockbolt) and a collar (C6L collar).
During installation, the collar is swaged on to the bolt, resulting in a permanent, high strength, vibration resistant installation.
Installs with consistency and provides a high uniform clamp force
. Heavy-duty design and long service life, high quality parts special treatment
。Low pressure can be action
. Stroke: 24 mm (0.94 inch)
. Working Air Pressure: 70 ~ 95 PSI (4.9 ~ 6.7 kg/cm2)
. Ave. Air Consumption: 4 CFM
. Traction Power: 4480 lbs (2033kg)
. Nosepieces: MAGNA-LOK 4.8mm(3/16”)~6.4mm(1/4”) MAGNA-BULB 4.8mm(3/16”)~6.4mm(1/4”) C6L 4.8mm(3/16”)~6.4mm(1/4”) MAGNA-GRIP 4.8mm(3/16”)~6.4mm(1/4”) BOM4.8mm(3/16”)
. Tool Weight: 1.74 kg
