PEMSERT® self-clinching flush nuts from PennEngineering® ideally suit attachment applications where a thin metal sheet requires load-bearing threads stronger than tapped holes but must remain flat without any protrusions on either side of the sheet. They can be installed before sheet bending and forming to provide threads for mating hardware in sections that otherwise would be inaccessible for fastener installation after chassis are formed. Their uniquely designed hexagonal head and clinch technology ensures high axial and torsional strength in service. Ultimately, the nuts install permanently, will never loosen or fall out, and leave surfaces unmarred to enhance the functional and cosmetic qualities of assemblies.
The product line includes PEMSERT F™ 300 Series stainless steel types for installation into steel or aluminum sheets and PEMSERT F4™ heat-treated 400 Series stainless steel versions specifically designed for installation into 300 Series stainless steel sheets. Both types are available in thread sizes #2-56 through ¼-20 and M2 through M6. Sheets can be as thin as .060”/1.53mm. For aerospace applications, F nuts can be ordered to conform with US NASM45938/4 aerospace standards.
