Performing Screws, EU (EN14592 & EN14566), Patented Screws, Stainless-Steel Screws, Ferrous & non-ferrous Sems, Nuts, Washers in Stainless & Carbon Steel, Stainless Cold Heading, Spring, Weaving and Welding Wire
Specifications :Performing Screws, EU (EN14592 & EN14566), Patented Screws, Stainless-Steel Screws, Ferrous & non-ferrous Sems, Nuts, Washers in Stainless & Carbon St
Materials :Carbon Steel, Stainless SteelPerforming Screws, EU (EN14592 & EN14566), Patented Screws, Stainless-Steel Screws, Ferrous & non-ferrous Sems, Nuts, Was
Sizes :Performing Screws, EU (EN14592 & EN14566), Patented Screws, Stainless-Steel Screws, Ferrous & non-ferrous Sems, Nuts, Washers in Stainless & Carbon St
Milled Drill Point SDS Screws, Self-drilling Screws
Specifications :Milled Drill Point SDS Screws, Self-drilling Screws
Materials :Carbon Steel, Stainless Steels
Sizes :3/4 inch ~ 3 inch
Patented Screws, Stainless-steel Screws, Ferrous & non-ferrous SEMS, Nuts, Washers in stainless & Carbon Steel, Stainless Cold Heading, Spring, Weaving and Welding Wire
Specifications :Patented Screws, Stainless-steel Screws, Ferrous & non-ferrous SEMS, Nuts, Washers in stainless & Carbon Steel, Stainless Cold Heading, Spring, Weavin
Materials :Stainless Steel / Carbon Steel / Brass
Sizes :Patented Screws, Stainless-steel Screws, Ferrous & non-ferrous SEMS, Nuts, Washers in stainless & Carbon Steel, Stainless Cold Heading, Spring, Weavin
Self-Drilling Screws, Self-Tapping Screw, Vyn-L-Hold Screws, Triple Spirals Screws, Concrete Screws, Liquid & Powder Painted Screws
Specifications :Self-Drilling Screws, Self-Tapping Screw, Vyn-L-Hold Screws, Triple Spirals Screws, Concrete Screws, Liquid & Powder Painted Screws
Materials :Stainless Steel / Carbon Steel / Brass
Sizes :Self-Drilling Screws, Self-Tapping Screw, Vyn-L-Hold Screws, Triple Spirals Screws, Concrete Screws, Liquid & Powder Painted Screws
Type 17 wood screw, Square thread, Triple Spirals Screws, Double Spirals, Hexlobular Thread
Specifications :Type 17 wood screw, Square thread, Triple Spirals Screws, Double Spirals, Hexlobular Thread
Materials :Stainless Steel / Carbon Steel / Brass
Sizes :Type 17 wood screw, Square thread, Triple Spirals Screws, Double Spirals, Hexlobular Thread
Tapping screw is a screw that can tap its own hole as it is driven into the material. Tapping screws are usually use in relatively soft material or sheet materials, such as wood.
(Type A,Type B, ype AB,Type D,Type F,Type G,Type U ,Dog Point,Type C,Drill Point)
*Product Range
Diameter: #0 ~ 1/2''(M1.6 / M12)
Length: 3mm ~ 400mm
*Materials
Stainless Steel: Carbon Steel / Brass
*Head Type
Pan / Flat / Oval / Truss / Button / Round / Round Washer
Hex Washer / Hex Flange / Hex
*Drive Type
Phil / Pozi / Torx / Square / Hex Drive / Phil Slot
Pozi Slot / Torx Slot / Phil Square / Slot
*Coatings
Ruspert / Darcomet / Xylan / Magni / E-Coating / Zinc Plated
*Head Painting
Liquid Plating, Powder Plating in all colors
Specifications :TAPPING SCREW
Materials :Stainless Steel , Carbon Steel / Brass
Sizes :TAPPING SCREW
1.Experience shows there is much better consistency in drilling speed i.e. the variation of drilling speed is
markedly reduced with milled point SDS vs the forged point counterparts.
2.The gripping onto the metal sheet being driven is invariably more stable and faster due to the configuration
of the milled point, thereby reducing the time required to grip and enter the metal sheet.
3.In real life applications, operators in the field would require less pushing force to drill a milled point SDS than
a forged point. This is a big plus and welcomed news for the operator.
*Diameters
#8、#10、#12、#14
*Head Sayles
Available head styles include Flat, IHW, PAN,ETC.,
*Finish
Passivation or various coatings and plating available and meet with ROSH equirement.
*Screw Lengths
3/4”~3”(19mm~80mm)
*Point
#3~#5 piont
3PT : For 5~6mm Steel Sheets
5PT : For 8~12mm Steel Sheets
*Materials
Carbon Steel & Stainless Steel
Specifications :Milled Point - Self Drilling Screw
Materials :Stainless Steel / Carbon Steel / Brass
Sizes :*Diameters #8、#10、#12、#14
SEMS screws combine two separate parts into one pre-assembled , low cost fastener with one or two washers under the head. SEMS screws allow for fast installation, permanence, and easy adaptability to many applications.
We probably make the smallest sems that there is-1.6mm diameter with double washers. Ferrous and nonferrous sems from 1.6mm to 12mm(1/2") diameters.
*Product Range
Diameter: #0 ~ 1/2''(M1.6 ~ M12)
Length: 3 ~ 100mm
*Materials
Stainless Steel / Carbon Steel / Brass
*Coatings
Ruspert / Darcomet / Xylan / Magni / E-Coating / Zinc Plated
*Head Painting
Liquid Plating, Powder Plating in all colors
Specifications :SEMS SCREWS
Materials :Stainless Steel / Carbon Steel / Brass
Sizes :Diameter: #0 ~ 1/2''(M1.6 ~ M12) Length: 3 ~ 100mm
Triple Thread Screw is a special design screw for the composite board application. It consists of 3 sections of threads, clockwise thread + conversed thread + clockwise thread from the point up to the head, with a reversed spiral ridge to combine 2 composite boards easily.
*Product Range
Diameter: #10(m4.8/m5)
Length: 35~100mm
*Materials
-Stainless Steel: 302HQ/304SS/305SS/316SS/410SS
-Carbon Steel
*Coatings
Ruspert / Darcomet / Xylan / Magni / E-Coating / Zinc Plated
*Head Painting
Liquid Plating, Powder Plating in all colors
Specifications :Triple Thread Screw
Materials :-Stainless Steel: 302HQ/304SS/305SS/316SS/410SS -
Sizes :Diameter: #10(m4.8/m5) Length: 35~100mm
*Product Range
Diameter:#6-1/2"(m3-m12)
Length:1/2"-16"(12-400mm)
*Materials
Stainless steel:AISI 304,305, 316, 410
Carbon & alloy steels
*Coatings
Whitford xylan, ruspert, dacromet clear & yellow zinc, etc.
*Head Painting
In All Colors
Very low drive-in-torque, a general 30-40 %less than the type 17 wood screws. Test results from independent lab as shown below. Do away with pre-drilling even on some of the densest woods and composites. Square sharp angle threads cut into the fiber rather than forcing into it allow for better gripping and resistance to stripping. Prolonged battery life for battery-operated guns. Minimize wood cracking problems.
Faster driving time means reduced labor costs and accelerated production time. Avoidance from screw breaking markedly reduce the subsequent costly salvage operations.
Specifications :Square Thread Screw
Materials :Stainless Steel / Carbon Steel / Brass
Sizes :Diameter:#6-1/2"(m3-m12) Length:1/2"-16"(12-400mm)
A machine screw is generally a smaller fastener (less than 1⁄4 inches (6.35 mm) in diameter) threaded the entire length of its shank that usually has a recessed drive type slotted, Phillips, etc.). Machine screws are also made with socket heads (see above), in which case they may be referred to as
socket head machine screws.
According to IFI, DIN, JIS and ISO specifications, we can also make our own screws according to customers' needs.
*Product Range
Diameter: #0 ~ 1/2'' (M1.6 ~ M12)
Length: 3mm ~ 400mm
*Materials
Stainless Steel: Carbon Steel / Brass
*Coatings
Ruspert / Darcomet / Xylan / Magni / E-Coating / Zinc Plated
*Head Painting
Liquid Plating, Powder Plating in all colors
Specifications :MACHINE SCREW
Materials :Stainless Steel: Carbon Steel / Brass
Sizes :Diameter: #0 ~ 1/2'' (M1.6 ~ M12) Length: 3mm ~ 400mm
*Product Range
Diameter: M3 ~ M6
Length: 15 ~ 300mm
*Materials
-Stainless Steel: 302HQ / 304SS / 305SS / 316SS / 410SS
-Carbon Steel
*Coatings
Ruspert / Darcomet / Xylan / Magni / E-Coating / Zinc Plated
*Head Painting
Liquid Plating, Powder Plating in all colors
Specifications :DOUBLE SPIRALS SCREW
Materials :Stainless Steel: Carbon Steel / Brass
Sizes :Diameter: M3 ~ M6 Length: 15 ~ 300mm
*Product Range
Diameter: #2~1/2''(M2.5~M12)
Length: 6 ~ 300mm
*Materials
Stainless Steel / Carbon Steel / Brass
*Coatings
Ruspert / Darcomet / Xylan / Magni / E-Coating / Zinc Plated
*Head Painting
Liquid Plating, Powder Plating in all colors
Specifications :HIGH-LOW SCREW
Materials :Stainless Steel / Carbon Steel / Brass
Sizes :Diameter: #2~1/2''(M2.5~M12) Length: 6 ~ 300mm
*Product Range
Diameter: M3 ~ M12
Length: 6 ~ 300mm
*Materials
Stainless steel / Carbon Steel / Brass
*Coatings
Ruspert / Darcomet / Xylan / Magni / E-Coating / Zinc Plated
*Head Painting
Liquid Plating, Powder Plating in all colors
Specifications :FURNITURE SCREW
Materials :Stainless Steel / Carbon Steel / Brass
Sizes :Diameter: M3 ~ M12 Length: 6 ~ 300mm
*Product Range
Diameter: #4 ~1/2''(M2.5 ~ M12)
Length:6 ~ 300mm
*Materials
-Stainless steel
-Carbon Steel
-Brass
Coatings
Ruspert / Darcomet / Xylan/ Magni / E-Coating / Zinc Plated
Head Painting
Liquid painting, Power Painting in all colors.
Specifications :WOOD SCREWS
Materials :Stainless Steel / Carbon Steel / Brass
Sizes :Diameter: #4 ~1/2''(M2.5 ~ M12) Length:6 ~ 300mm
*Product Range
Diameter: #6 ~ #14 (M3 ~ M6.3)
Length: 12.7 ~ 100mm
*Head Type
IFI, DIN, SPECIAL HEAD
*Materials
-Stainless Steel: 302HQ / 304SS / 305SS / 316SS / 410SS
-Carbon Steel
*Coatings
Ruspert / Darcomet / Xylan / Magni / E-Coating / Zinc Plated
*Head Painting
Liquid Plating, Powder Plating in all colors
Specifications :Self-Drilling Screw- Forge Point
Materials :Stainless Steel / Carbon Steel
Sizes :Diameter: #6 ~ #14 (M3 ~ M6.3) Length: 12.7 ~ 100mm
*Product Range
Diameter: #6 ~ #14
Length: 3/4 ~ 6'' (20 ~ 150mm)
*Materials
-Stainless Steel: 302HQ / 304SS / 305SS / 316SS / 410SS
-Carbon Steel
*Coatings
Ruspert / Darcomet / Xylan / Magni / E-Coating / Zinc Plated
*Head Painting
Liquid Plating, Powder Plating in all colors
Specifications :DECKING SCREWS
Materials :DECKING SCREWS
Sizes :Diameter: #6 ~ #14 Length: 3/4 ~ 6'' (20 ~ 150mm)
Liquid Plating, Powder Plating in all colors
Specifications :Head Panting
Materials :Stainless Steel / Carbon Steel / Brass
Sizes :Head Panting
Ruspert / Darcomet / Xylan / Magni / E-Coating / Zinc Plated
Specifications :COATING
Materials :COATING
Sizes :COATING
Pre-applied Nylon patch thread locking is a prevailing torque patch used to prevent fasteners becoming loose due to vibration or no load. When the fastener is assembled onto a mating thread, the patch forces the threads of the fastener to be wedged tightly against the mating thread, providing resistance to loosening. The amount of nylon applied is controlled and is designed to ensure a good lead-in and provide a gradual development of locking torque to pre-determined specifications.
Specifications :PATCHING
Materials :Stainless Steel / Carbon Steel / Brass
Sizes :PATCHING
PLATING
Specifications :PLATING
Materials :PLATING
Sizes :PLATING
We provide a wide range of stainless steel wires
As a leading manufacturer of stainless steel fasteners, we have our own wire drawing machine, we provide stainless steel wire with competitive price and high quality.
* 304SS *305SS *316SS *410SS
Specifications :Stainless Wire
Materials :*304SS *305SS *316SS *410SS
Sizes :Stainless Wire
