Bossard (Shanghai) Introduces a Simulated Assembly Workstation to Increase Torque Testing Range Up to 350 Nm

Add to my favorite

2023-09-14

This assembly simulation system is equipped with a robotic arm that simulates actual assembly conditions to obtain the torque and angle relationships of the assembly setup, thus verifying the accuracy of the assembly process.

"The accuracy of the high torque assembly process is important for critical applications in industries such as rail transportation and automotive. The introduction of the simulated assembly workstation means that we are in a position to help these customers solve the problems they may encounter in high torque threaded connection applications by helping them to find and validate suitable solutions," said the engineering department of Bossard Fastening Solutions (Shanghai).

In addition, when coupled with ultrasonic equipment, the simulated assembly system can also obtain fastening parameters such as torque, angle, axis force, coefficient of friction, coefficient of torque, and a variety of assembly parameter curves of the threaded connection during the fastening process, which is conducive to a more detailed analysis of threaded connection.
